UT SERIES · AVAILABLE NOW
All-Metal Spinning Reel, Saltwater Jigging, Sizes 4000–10000
$160.00
Specifications
Product specifications
Available options
| Model | CW4000 · CW4000H · CW5000 · CW5000H · CW6000 · SW4000XG · CW10000 · CW10000H · SW5000XG · SW6000HG · SW10000HG |
|---|
Product Details
| Body Material | Full Metal Fuselage |
|---|---|
| Application | Freshwater / Saltwater Dual Use |
| Feature | Anti-Corrosion / Rust-Resistant |
| Foot length | 67 mm |
| Height | 129 mm |
| Length | 150 mm |
| Rotor Width | 105 mm |
| Model Shown | 10000HG |
| Main Shaft Material | Stainless steel |
| Main Gear Material | High-strength imported bronze / brass |
| Bearing Material | Stainless steel |
| Manufacturing Process | Precision cold forging |
| Bearing Count | 9+1 |
| Model | Gear Ratio | Line Capacity | Drag Power | Ball Bearings | Weight |
|---|---|---|---|---|---|
| SW-4000XG | 6.2:1 | PE 3.5/250 4/220 MM-M 0.26/290 0.31/230 | 25 kg (55.1 lb) | 9+1BB | 345 g |
| SW-5000XG | 6.2:1 | PE 4/240 5/160 MM-M 0.31/250 0.33/230 | 25 kg (55.1 lb) | 9+1BB | 355 g |
| SW-6000HG | 6.0:1 | PE 4/370 5/250 MM-M 0.3/420 0.35/330 | 35 kg (77.2 lb) | 9+1BB | 500 g |
| SW-10000HG | 6.0:1 | PE 5/300 6/250 MM-M 0.4/300 0.45/250 | 35 kg (77.2 lb) | 9+1BB | 530 g |
* The above data comes from store testing, please allow for slight errors.
Born for Big Fish - SW Series Spinning Reel
- Full metal fuselage construction
- Freshwater and saltwater dual use
- Anti-corrosion design
- Lifetime free repair and maintenance service included with purchase
- Note: The above data is from store testing; please allow for slight errors.
Spinning Reel Anatomy & Features
- Drag knob at top of spool
- Metal spool and metal bail wire
- Line roller guide and metal rotor
- Metal body, side cover, and large metal handle knob
Spinning Reel Dimensions (10000HG)
- Foot length: 67 mm
- Overall height: 129 mm
- Overall length: 150 mm
- Manual measurement data provided for 10000HG; slight variance may exist
- Rotor width: 105 mm
- Model shown: 10000HG
- Manual measurement tolerance may apply; refer to actual product
Spool Dimensions
- SW4000XG: 31 mm top diameter, 19 mm spool height, 45 mm total height, 51 mm bottom diameter
- SW5000XG: 31 mm top diameter, 19 mm spool height, 46 mm total height, 55 mm bottom diameter
- SW6000HG: 33 mm top diameter, 21 mm spool height, 57 mm total height, 61 mm bottom diameter
- SW10000HG: 33 mm top diameter, 22 mm spool height, 58 mm total height, 66 mm bottom diameter
Full Metal Fuselage
- Focus on detail and quality
- High-strength aluminum alloy main body, cover plate, and flywheel provide powerful support for all kinds of fishing environments
Seiko Brass Gear
- Stainless steel main shaft
- Precision brass main gear made of high-strength imported bronze material
- Stainless steel bearing and pinion gear system
- Precision cold forging technology for durable, high-hardness performance
03 9+1 Bearings
- Large-diameter slider for enhanced spool stability.
- Durable stainless steel main shaft.
- Audible clicker spring mechanism.
- 9+1 high-performance bearing system for smooth rotation.
